Compatibility in mind & Jam-Free™ Technology

Polymaker CosPLA Version B is compatible with a wide range of 3D printers and works well with many common printing surfaces and a 30 - 60°C heated bed. Polymaker CosPLA Version B is manufactured with Polymakers Jam-Free™ technology which improves the heat stability of the filament with softening temperatures over 140°C and leads to excellent printing quality with zero risk of nozzle jams caused by heat creep ^[1]. Manufactured with Polymakers industry leading compounding and extrusion systems, Polymaker CosPLA Version B filament is made with the highest quality ingredients and formulated to deliver a reliable 3D printing filament for cosplay and prop applications.



^[1] Heat creep is the the process of heat spreading irregularly throughout the hot end, one common example is with all metal hot end designs. Once heat creeps towards the cold end, the PLA filament softens prematurely in the cold end and expands resulting in a jam. Polymakers Jam-Free™ technology increases the heat resistance of the filament itself (not the printed part) to 140˚C which prevents the filament from prematurely softening in the cold end and can still melt rapidly once entering the heating zone.

Printing Settings

Based on 0.4 mm nozzle. Printing conditions may vary with different printers, higher speeds / flow rates and nozzle diameters.

For other tips printing Polymaker CosPLA contact us!

Specification

Compatibility

Polymaker CosPLA PLA has been engineered with compatibility in mind to print excellently on a wide range of 3D printers. The Jam-Free™ technology implemented into Polymaker CosPLA can improve compatibility with all metal hot end designs that suffer from heat creep.

Of course with thousands of unique 3d printer models on the market, we can't guarantee each filament type will work with every 3D printer.

STORAGE & DRYING

All plastics are hygroscopic meaning they absorb moisture from the air which can affect printing quality and strength of printed parts. How quickly this absorption occurs depends on the material and your environment. Polymakers PLA filaments are dried and packaged in a vacuum sealed bag with desiccant to ensure the best printing quality. When not in use CosPLA should be stored away from sunlight and sealed in the packaged resealable bag.

Although filaments can be dried, drying will speed up the aging process of the plastic making it more brittle over time. Preventing the filament from absorbing moisture in the first place is the best solution to keep your filament working to its maximum potential. For long term storage we highly recommend storing in a sealed container with dry desiccant that reduces the relative humidity to 10-20% RH.

If you hear popping sounds and notice that the surface quality of your print is uneven or the colour is not consistent, this is a likely indicator that the filament has absorbed too much moisture.

FAQ

Q: Does Jam-Free™ technology prevent all filament jamming?
A: Jam-Free™ technology is designed to prevent jamming caused by heat creep. There are many reasons why a material may jam, such as a partially blocked nozzle, printing with the wrong extruder temperature or incorrect nozzle height; Polymaker's Jam-Free™ technology won't prevent jamming in these cases.

Q: Is Polymaker CosPLA Version B a PLA+ material?
A: Yes, Polymaker CosPLA Version B could be defined as a PLA+ material as it delivers significantly improved impact strength compared to regular PLA. Both CosPLA Version B and PolyMax™ PLA are a popular choice among prop makers.

Q: Can PLA be printed at large scales without warping?
A: One of the benefits of PLA is the ability to print large parts with excellent dimensional stability and we have many customers printing large full-size printing projects in Polymaker CosPLA. When printing large parts it is recommended to print PLA with a heated bed and to partially enclose the printer to protect the print from drafts and sudden temperature changes. Please note that while PLA materials don't warp in most situations, printing with poor first layer adhesion can cause any material to warp and printing or the heated bed too hot can cause PLA filament to undergo a crystallisation process which generates internal stresses and warping.

Q: What support materials can I use with this product?
A: If your 3D printer supports multi-material 3D printing, Polymaker CosPLA is compatible with Polymaker’s PolySupport™ and PolyDissolve™ S1 filament. PolySupport™ is a breakaway support material which can be easily peeled away and PolyDissolve™ S1 is a water dissolvable support material, ideal for complex geometries.

Q: Should I rewind this filament if I want to use it with a different spool?
A: We strongly advise against tampering with the product by rewinding. See our article for full details about the risks. All Polymaker filaments are wound with tension but without strain. Rewinding completely rearranges the curvature of the winding and this strain over time can cause most plastics to catastrophically break. If for some reason your printer is locked into fitting less than standard sized spools, there may be safe printable adaptors or external mounting solutions available.

Don't know where to start? Or which filament will suit your application? We have a broad range of support options including telephone support. Contact us today!
