Polymaker
Fiberon PETG-rCF08 500g 1.75mm Filament by Polymaker
Fiberon PETG-rCF08 500g 1.75mm Filament by Polymaker
Out of stock
Couldn't load pickup availability
Fiberon PETG-rCF08 is an easy to use general use composite PETG filament with recycled carbon fiber reinforcement.
- Versatile PETG-CF with 8% carbon fiber reinforcement.
- Easy-to-use composite filament, billed as the "PLA of engineering materials".
- Printability and performance of PETG with enhanced stiffness.
- Low creep and exceptional dimensional accuracy.
- Cost-effective and high speed capable.
- Reliable and consistent tolerance (1.75mm diameter +/- 0.03mm)
Our entry-level composite filament featuring recycled carbon fibers. Inheriting the printability and performance of PETG, while gaining enhanced stiffness from the carbon fiber reinforcement. Print high-speed, moisture-insensitive, and low-creep prototypes with exceptional dimensional accuracy. PETG-rCF08 strikes the perfect balance between affordability and functionality, empowering you to quickly create durable, accurate prototypes.
Features
- Affordable & Easy-to-use - Fiberon™ PETG-rCF08 is a cost-effective recycled carbon fiber reinforced PETG filament billed as the "PLA of engineering materials". It inherits the comprehensive performance of PETG, featuring recycled carbon fiber for enhanced surface texture and improved mechanical properties.
- Recycled Carbon Fibers- Fiberon™ PETG-rCF08 utilises carbon fibers from end-of-life wind turbine blades, these fibers are certified to the Global Recycled Standard by TÜV Rheinland. The use of recycled carbon fibers delivers a more sustainably sourced composite filament while maintaining the mechanical strength that users come to expect from carbon-fiber reinforcement.
- Dimensional Accuracy & Moisture Insensitivity - By delivering fantastic dimensional accuracy, low moisture sensitivity[1] and low shrinkage during printing, Fiberon PETG-rCF17 is well suited for rapid prototyping and a wide range of functional applications requiring durability, accuracy and surface finish.
- High Speed Capable - Fiberon PETG-rCF08 has been developed with printer compatibility in mind and is high speed capable, enabling printing up to 300mm/s on suitable high speed printers.
- Excellent Surface Finish - Fiberon™ PETG-rCF08 3D prints and renders parts with an attractive surface finish thanks to the PETG's excellent fluidity as a matrix material and the 8% carbon fiber reinforcement.
[1] Low moisture sensitivity does not describe whether the filament should be kept dry for optimal print quality. This description of moisture insensitivity is in the context of the end-use application where extremely moisture sensitive materials like PA6-CF see a significant reduction in mechanical properties as the part absorbs moisture. With PETG-CF moisture absorption is minimal and doesn't impact the mechanical properties of the part. For best printing results PETG-CF should still be kept dry during printing and storage.
Technical Data
All PETG-rCF specimens were printed with 270°C nozzle temperature, 60°C bed temperature, cooling fan 0 - 50%. Samples were printed with 100% infil, 2 shells and 3 top & bottom layers.
FIBERON PETG-CF 08 THERMAL PROPERTIES
| Value | Testing Method | |
| Glass Transition | 69.7°C | DSC, 10°C/min |
| Heat Deflection Temperature |
0.45MPa - 68.6°C HDT Curve |
ISO 75 |
| Vicat Softening Temperature | 81.6°C | ISO 306, GB/T 1633 |
FIBERON PETG-CF 08 MECHANICAL PROPERTIES
| Value | Testing Method | |
| Youngs Modulus (X-Y) |
3710.1 ± 151.1 MPa | ISO 527, GB/T 1040 |
| Youngs Modulus (Z) |
2651.9 ± 51.0 MPa | |
| Tensile Strength (X-Y) |
59.8 ± 0.3 MPa | ISO 527, GB/T 1040 |
| Tensile Strength (Z) |
41.1 ± 4.1 MPa | |
| Bending Strength (X-Y) |
94.6 ± 1.3 MPa | ISO 306, GB/T 1633 |
| Bending Strength (Z) |
47.8 ± 2.4 MPa | |
| Charpy Impact Strength Notched (X-Y) |
4.0 ± 0.9 kJ/m2 | ISO 179, GB/T 9343 |
Data taken from Polymakers Technical Data Sheet and is intended for reference and comparison purposes only. Due to the nature of 3D printing, data should not be used for design specifications or quality control purposes.
Printing Settings
| Nozzle Temperature | 240°C - 270°C |
|---|---|
| Build Plate Temperature | 60°C - 70°C |
| Enclosure | Recommended |
| Chamber Temperature | Room temperature is suitable. |
| Cooling Fan | 0% - 50% ON for better quality OFF for better strength |
| Printing Speed | Up to 300mm/s |
| Retraction | The ideal retraction settings vary from printer to printer and depend on the hot end. The following settings have been a good starting point for many machines. Direct Drive: Retraction distance of 3mm with retraction speed of 40mm/s Bowden: Retraction distance of 6mm with retraction speed of 60mm/s |
| Recommended Support Material |
Self-supports. |
The above are printing recommendations based on 0.4 mm nozzle. Please note ideal printing conditions may vary depending on your 3D printer setup. For high speed 3D printers, make sure to use a suitable printer and increase your extrusion temperature in order to use higher printing speeds.
Hardened nozzles such as hardened steel are less conductive than brass, so depending on your 3D printer, printing with a higher extrusion temperature may be required when using a wear resistant nozzle.
We highly recommend to use a wear resistant nozzle when printing Fiberon™ PETG-rCF08. Hardened steel offers much better wear resistance than brass. The second consideration it to keep PETG-rCF dry during printing and storage. See "Storage and Drying" details below for instructions to protect Fiberon™ PETG-rCF08.
Specific Printing Tips for Fiberon™ PETG-rCF08.
- Fiberon™ PETG-rCF08 is a very stiff filament due to its carbon fiber reinforcement. When not in use, please use tape to secure the filament tip to the spool the rather than attempting to bend the filament through the spool guide hole. During printing it is required to have a smooth feeding path to ensure optimal feeding. For example we recommend avoiding excessive bending in the filament guide system.
- Fiberon™ PETG-rCF08 can easily damage a brass nozzle after a few hundred grams of printing. Nozzles come in many different materials from soft to hard and the heat conductivity of a nozzle can change depending on what material it is made of. Hardened steel is more abrasion resistance than brass or a nickel plated nozzle.
- Inter-layer strength can depend significantly on your extrusion temperature which is a result of your printing speed, nozzle type and hot end. A higher nozzle temperature / extrusion temperature can offer significant benefits in regards to inter-layer strength. When printing Fiberon™ PETG-rCF08 at low temperature (240 ˚C) on a general desktop 3d printer, it is recommended to use a hardened nickel-coated brass nozzle which offers better thermal conductivity than hardened steel or a high flow hot-end to ensure better melt performance.
Specification
| Net Weight | 500g |
|---|---|
| Material Type | PETG with 8% recycled chopped carbon fiber by weight. |
| Density | 1.3 (g/cm3 at 23˚C) |
| Equilibrium Water Absorption (70% RH, 23°C) |
0.55% |
| Colour |
Black |
Compatibility
Fiberon™ PETG-rCF08 has been engineered so users can print strong carbon fiber filled parts on a wide range of 3D printers. As the carbon fiber in this material is highly abrasive we recommend customers first check that their 3D printer is equipped to print abrasive materials before purchasing this product.
Aside from wear resistance, there are a few important considerations for this material that we recommend.
Reinforced filaments tend to be much stiffer than other standard filaments and this can cause problems when passing the filament through a printer’s feeding system. For a steady and uninterrupted flow of filament, it is recommended to take extra care and make sure your filament guide system is smooth and with minimal bends. Brass nozzles give a better thermal conductivity than hardened nozzles such as stainless steel. Depending on your 3D printer, printing with higher extrusion temperatures may be required when using specialty nozzles to ensure the correct extrusion temperature is achieved.
Of course with thousands of unique 3d printer models on the market, we can't guarantee each filament type will work with every 3D printer. Slicer experience and setting adjustment is always required to get the most out of a material. Before jumping into an ambitious project we always recommend printing some known calibration tests to build or make adjustments to the filament profile.
Technical Data & Safety Data Documents
We have full MDS and technical data sheets for Fiberon™ PETG-rCF08 and all other Fiberon filaments from Polymaker. Contact us to enquire!
The typical values presented in Polymakers data sheet are intended for reference and comparison purposes only. Due to the nature of 3D printing they should not be used for design specifications or quality control purposes.
STORAGE & DRYING
All plastics are hygroscopic meaning they absorb moisture from the air which can affect printing quality and strength of printed parts. How quickly this absorption occurs depends on the material and your environment. Fiberon™ PETG-rCF08 filaments are dried and packaged in a vacuum sealed bag with desiccant to ensure the best printing quality. When not in use Fiberon™ PETG-rCF08 should be stored away from sunlight and sealed in the packaged resealable bag.
Although filaments can be dried, drying will speed up the aging process of the plastic. Preventing the filament from absorbing moisture in the first place is the best solution to keep your filament working to its maximum potential. For long term storage we highly recommend storing in a sealed container with dry desiccant that reduces the relative humidity to 10-20% RH.
In-house we manage our filaments with Polymakers PolyDryer™ which keep offers best-in-class sealing to protect filaments from absorbing moisture
If you hear popping sounds and notice that the surface quality of your print is uneven or the colour is not consistent, this is a likely indicator that the filament has absorbed too much moisture. Spools of Fiberon™ PETG-rCF08 can be dried with Polymaker PolyDryer™ using power level 2 for 6 hours.. Alternatively if you have a convection oven that is accurate at low temperatures, users can dry filament in a preheated convection oven at 65˚C for up to 3 hours. Results may vary depending on the accuracy of your oven so please be conservative. For more information about filament drying please read our user guide.
FAQ
Q: Should PETG-rCF be annealed?
A: No, due to the amorphous nature of PETG, annealing PETG-r-CF is not required and will not provide added thermal or mechanical properties. This is in contrast to PET-CF which is semi-crystalline and does see benefit from annealing.
Q: Do I need an enclosure to print PETG-rCF?
A: As a general rule, no an enclosure is not required, however this is really dependent on the ambient room temperature, size, geometry and infil density of your parts. When printing without an enclosure it is important to keep the printer away from cold drafts that could impact the print.
Q: Should I rewind this filament if I want to use it with a different spool?
A: We strongly advise against tampering with the product by rewinding. See our article for full details about the risks. All Polymaker filaments are wound with tension but without strain. Rewinding completely rearranges the curvature of the winding and this strain over time can cause most plastics to catastrophically break. If for some reason your printer is locked into fitting less than standard sized spools, there may be safe printable adaptors or external mounting solutions available.
Don't know where to start? Or which filament will suit your application? We have a broad range of support options including telephone support. Contact us today!
| Filament | |
| Diameter | 1.75mm |
| Spool Weight | 500g |
